DFW - Dallas Fort Worth Intl

Are you familiar with this airport? Help out other pilots by adding your local knowledge.

Tags

Public

Undocumented

METAR / TAF

Edit Tags

Food

Camping

Lodging

Car Rental

Bicycles

Swimming

Golfing

Fishing

Hot Springs

Museum

Flying Clubs

Airpark

Upcoming Events

No upcoming events. Is anything happening here soon?

Description

Transient Parking

Fuel Location

Landing & Tie-down Fees

Crew Car Availability

Flying Clubs

WiFi Access

Airport Statistics

Location: Dallas Fort Worth, TX

Elevation: 606ft

Sectional: Dallas Ft Worth

Activation date: Jan 1974

Fuel: 100LL, A (prices)

Runway 18L/36R: 13,401ft

Runway 18R/36L: 13,400ft

Runway 17C/35C: 13,400ft

Runway 17R/35L: 13,400ft

Runway 13R/31L: 9,300ft

Runway 13L/31R: 9,000ft

Runway 17L/35R: 8,500ft

Access: Open to the public

Edit airport annotations

Airport Webcams

No webcams added yet.

Remarks

And dallas co.
Birds on & invof arpt.
Ppr fm the primary tenant airlines to operate within the central terminal area. proper minimum object free area distances may not be maintained for ramp/apron taxilanes.
Ppr from arpt opns for gen avn acft to procd to airline trml gate excp gen avn fac.
Std sawed grooving 160 ft wide full length rys 13l/31r; 18l/36r & 17r/35l. std grooving 130 ftwide full length rys 17l/35r; 18r/36l; 13r/31l & 17c/35c.
Arpt under construction; paew in movement areas.
Tkof dstc for ry 17r fm twy eg is 13082 ft & fm twy eh is 12816 ft.
Land & hold short signs on ry 17c at twy 'b' 10,460 ft s of ry 17c thld; ry 18r at twy 'b' 10,100 ft s of ry 18r thld; ry 35c at twy 'ej' 9050 ft n of ry 35c thld; ry 36l at twy 'z' 10,650 ft n of ry 36l thld; lgtd & mkd with in-pavement pulsating white lgts.
Tkof dstc for ry 36r fm twy wp is 12,815 ft; fm twy wq is 13,082 ft.
Tkof dstc for ry 17l fm twy q2 is 8196 ft.
Twys may require judgmental oversteering for large acft.
Tkof dstc for ry 35r fm twy q9 is 8196 ft.
Tkof dstc for ry 35l fm twy eq is 13084 ft & fm twy ep is 12811 ft.
Twy edge reflectors along all twys.
Terminal b apron taxilane btn apron entrance/exit point taxilanes 107 & 117 clsd to acft with wingspan 94 ft and greater.
Tkof dstc for ry 18l fm twy wg is 13,082; fm twy wh is 12,815.
Ppr ga operations 0000-0500; call arpt opns 972-973-3112.
Apron entrance/exit point 124 clsd to acft with wingspan greater than 213 ft.
Twy a6 clsd to acft with wingspan 171 ft and greater.
Tkof dstc for ry 17c fm twy eg is 13,082 ft.
Tkof dstc for ry 18r fm twy wg is 13,082 ft.
Apron entrance/exit points 9, 32, 33, 34, 35, 36, 37, 38, & 53 clsd to acft with wingspan greater than 135 ft.
Asde-x in use. operate transponders with altitude reporting mode and ads-b (if equipped) enabled on all airport surfaces.
Ppr acft with wingspan 215 ft or greater (group vi) call arpt opns 972-973-3112 for follow-me services while taxiing to & from ramp & rys.
Ry visual screen 20 ft agl 1180 ft s aer 35c.
Ry visual screen 22 ft agl 1179 ft s aer 35l.
Acft using terminal e gates e2-e17 must obtain approval from ramp 131.0 prior to entering ramp and prior to pushback. acft using terminal e gates e-18-e38 must obtain approval from ramp 128.825 prior to entering ramp and prior to pushback.
A380 opns only auzd on rwys 18r/36l and 18l/36r. b747-8 opns only auzd on rwys 18r/36l, 18l/36r and 17r/35l. ctc arpt opns for addnl info.
Acft at east air freight must contact dfw twr at 127.5 prior to taxi out.
Apron entrance/exit points 5, 7, 42, 44, 48, 49, 51, 52, 117, 118 and 122 clsd to acft with wingspan greater than 118 ft.
Apron entrance/exit points 1 and 2 clsd to acft with wingspan greater than 89' except ppr.
Apron entrance/exit point 3 clsd to acft with wingspan greater than 214 ft except ppr.
Apron entrance/exit points 31 and 39 clsd to acft with wingspan greater than 167 ft.
Unless otherwise specified, all apron entrance/exit points clsd to acft with wingspan greater than 214 ft except ppr.
Ry status lgts in opn.
Apron entrance/exit points 110, 111, 112, 113, 114, 115, and 116 clsd to acft with wingspan greater than 94 ft.
Acft using terminal b gates b1-b17, all terminal d gates, and apron entry points 117-150 must obtain approval from ramp 129.825 prior to entering ramp and prior to pushback.
Apron entrance/exit points 22, 24, 105, and 107 clsd to acft with wingspan greater than 125 ft.
Acft using twy ha north of twy b must obtain approval from ramp 129.825 prior to entering ramp.
Clsd 2200-0600 excp ppr.
Clsd 2200-0600 excp ppr.
Clsd 2200-0600 excp ppr.
Antenna on building.
Acft using terminal b gates b18-b49 must obtain approval from ramp 130.10 prior to entering ramp and prior to pushback.
Acft using terminal a gates a8-a39 and terminal c gates c2-c12 must obtain approval from ramp 131.275 prior to entering ramp and prior to pushback.
Acft using terminal c gates c14-c39 must obtain approval from ramp 131.80 prior to entering ramp and prior to pushback.
