This airport has been surveyed by the national geodetic survey.
Flocks of birds on & invof arpt.
Special air traffic rules--part 93; high density arpt; prior reservation required; see aim.
Mag anomalies may affect compass hdg when using extension rys 13 & 22 for tkof.
Twys g p r & u concrete deck rstd to 5kt turns; 10kts straight.
Coded transponder required. vfr reservation info avbl on atis.
Ship masts in apch ry 31.
For noise abatement rstrns call 212-435-3782 durg nml bus hrs.
B767-400 aircraft restricted to 10 knots on taxiways dd,z,b and aa.
Ry 13 papi and ils not coincidental.
H1 lctd intxn twys bb btwn twys d & f.
Twy 'f' & twy 'd' west of twy 'bb' clsd to acft with wingspans in excess of 125 ft.
Asde-x in use. operate transponders with altitude reporting mode and ads-b (if equipped) enabled on all airport surfaces.
Obst sign structure unkn (39 agl) 500 ft e ry 4/22 cntrln & 4,800 ft s ry 13/31 cntrln.
Helicopter pad located at the intersection of twy d and twy f clsd indef.
Runway status lights in operation.
Ovhd pax bridges on n side of terminal b prvd 50 ft tail hgt clnc when on taxilane cntrln.
Port authority of new york and new jersey.
Leasee. property owned by the city of new york.
Engineered materials arresting system (emas) 215 ft in length by 170 ft in width lctd at the der 04.
Emas partially damaged resulting in reduced arresting capability. engineered materials arresting system (emas) 327 ft in length by 170 ft in width lctd at the der 13.
Engineered materials arresting system (emas) 272 ft in length by 170 ft in width lctd at the der 22.
Engineered materials arresting system (emas) 215 ft in length by 170 ft in width lctd at the der 31.
This ry exist to support the tkd lda/dme associated with ry end 22x.
+11 ft fence 245 ft r of ry end.
Papi ry 13 unusbl 8 degs left of cntrln and 9 degs right of cntrln. papi & rnav glidepath not coincident.
Papi & glidepath not coincident.
Papi & rnav glidepath not coincident.
Rwy 13/31: nw 944 ft of rwy is a deck ovr wtr; rwy friction may be different than rmng ptn of rwy durg wint wx.
Rwy 04/22: ne 1776 ft of rwy is a deck ovr wtr; rwy friction may be different than rmng ptn of rwy durg wint wx.
