LGB - Long Beach (Daugherty Fld)

Tags

Public

METAR / TAF

Edit Tags

Food

Camping

Lodging

Car Rental

Bicycles

Swimming

Golfing

Fishing

Hot Springs

Museum

Flying Clubs

Airpark

Upcoming Events

No upcoming events. Is anything happening here soon?

Description

Transient Parking

Last updated: 2023-04-13 19:03:23 PDT

Fuel Location

Last updated: 2023-04-13 19:03:23 PDT

Landing & Tie-down Fees

Crew Car Availability

Flying Clubs

WiFi Access

Airport Statistics

20%

Are you familiar with this airport? Help complete its documentation by adding some of the following info if applicable:

Local flying clubs
Tags
Landing & tie-down fees

Location: Long Beach, CA

Elevation: 60ft

Sectional: Los Angeles

Activation date: Apr 1940

Fuel: 100LL, A, UL94 (prices)

Runway 12/30: 10,000ft

Runway 08L/26R: 6,192ft

Runway 08R/26L: 3,918ft

Runway H3: 300ft

Runway H2: 20ft

Runway H4: 20ft

Runway H5: 20ft

Access: Open to the public

Current Weather — VFR

Weather data is strictly informational and not for flight planning purposes.

METAR

2025-12-05 01:53:00 PST

Ceiling:	Sky clear
Wind:	Calm
Temperature:	51°F
Dewpoint:	35°F
Weather:	N/A
Visbility:	10SM

Raw: METAR KLGB 050953Z 00000KT 10SM CLR 11/02 A3012 RMK AO2 SLP198 T01060017

Edit airport annotations

Airport Webcams

No webcams added yet.

Remarks

Prvdd day use only; opns coordinated with atct.
Ry 12/30 faa strength evaluation dc-10-10 440000 lbs; dc-10-30 550000 lbs; l-1011 460000 lbs.
All rys clsd 2200-0700 lcl excp ry 12/30.
Ry 12/30 lgtd distance remaining signs west side.
Noise limits (decibels sgl event noise exposure level) rwy 26r tkof 92.0 ldg 88.0; rwy 08l tkof 88.0 ldg 92.0; rwy 26l tkof 95.0 ldg 93.0; rwy 08r tkof 95.0 ldg 92.0. rwys 12 & 30 0700-2200 tkof 102.5 ldg 101.5; 0600-0700 & 2200-2300 tkof 90.0 ldg 90.0; 2300-0600 tkof 79.0 ldg 79.0.
Twys d3 and l3 wgt limits a340 dc10 30/40 & md11 541000 lbs; c17 450000 lbs.
6 ft lighted chain link fence lctd 130 ft south of cntrln of twy f. fence begins nw corner of atct & extends 400 ft to west.
Engine run-ups, other than pre-flight, are limited to hrs of 0700-2100 weekdays & 0900-2100 weekends & holidays.
Helipad h2, h4, & h5 20 x 20 asph. helipad h3 35 x 300 asph.
Max ldg wgt for c17at or byd glide slope or ry aiming point marking 538600 lbs; ry 30 ldg prior tory aiming point marking 344000 lbs.
Airships moored in infield and operating invof arpt.
Max tkof wgt dc-10 30/40 & md-11 588100 lbs; c-17 538600 lbs. twys d3 & l3 wgt limits a-340 dc-10 30/40 & md-11 541000 lbs; c-17 450000 lbs.
The flwg wt lmtns are imposed based on potential structural strength of lakewood blvd and spring street tunnels: rwy 12/30 max ldg wts a-330 347000 lbs; a-340 379000 lbs; dc-10-10, dc-10-30/40 & md-11 379000 lbs; l-1011 354000 lbs. rwy 12/30 max tkof wts dc-10-30/40 & md-11 588000 lbs; c-17 538600 lbs.
No twy access to rwy 08l w of twy d; 4897 ft remaining on rwy 08l from twy d.
24 hr prior notice reqd for mil jets and civilian non-stage iii jets; ctc noise ofc 562-570-2635 mon-fri 0800-1700.
Birds on & inv of arpt
Trng helipads h2, h3 & h4 located n of rwy 12/30 midfield btn twys g & k. trng helipad h5 located s of rwy 12/30 btn twys d & j for hover work only.
No running ldgs/tkofs by hels with skid-type ldg gear, on rwy 08l-26r. rolling ldgs/tkofs with hels with wheel-type ldg gear are pmtd.
Touch & go, stop & go, practice low apch, vfr practice missed apch only pmtd 0700-1900 wkdays & 0800-1500 wkends & hols only on rwys 08l/26r & 08r/26l.
No fld cond notams avbl 2200-0700.
All acft on or entering left downwind rwy 26l must remain north of signal hill unless specifically instructed by atc otherwise.
All acft on downwind rwy 26l are not auth to turn base or begin descent until east of rwy 30 unless specifically instructed to do so by atc.
All acft on downwind rwy 08l are not auth to turn base or begin descent until west of rwy 12 unless specifically instructed to do so by atc.
For cd when atct clsd ctc socal apch at 800-448-3724.
Rwy 8r/26l not avbl for sked acr opns with more than 9 psgr seats or unsked acr opns with at least 31 psgr seats.
When atct clsd actvt malsr rwy 30; reil rwys 08r, 12, 26l & 26r; papi rwys 12, 08r, 26l & 26r; hirl rwy 08r/26l; mirl rwy 08l/26r - ctaf. hirl, tdzl & cl lights rwy 12/30 oper consly when atct clsd. papi rwy 30 oper consly.
Juan lopez-rios (deputy dir) 562-570-2608. ron reeves (supt arpt opns) 562-570-1251. arpt bur fax 562-570-2601; noise ofc 562-570-2635; pub affairs 562-570-2665.
Pcr value: 721/f/a/x/t
Apch ratio 20:1 to dsplcd thr.
Apch ratio 50:1 to dsplcd thr.
Apch ratio 34:1 to dsplcd thr.
Apch ratio 50:1 to dsplcd thr.
Lgtd tower 152 ft agl 2500 ft west & 500 ft south of ry thld.
Pcr value: 599/f/b/x/t
Rwy 08r/26l not avbl for part 121/part 380 ops with sked pax carrying ops more than 9 pax seats and non-sked pax carrying ops more than 30 pax seats.
